Centrifugal Process Pumps Manufacturers

Sujal Engineering provides the best range of Centrifugal Process Pumps famous with SCPP – Series in a market.

Our specially designed Centrifugal Process Pump is the most preferred hydraulic pump for industrial and domestic uses. It is used to move or raise the pressure of a liquid. High-quality impeller which is used in our centrifugal pump rotates the liquid and the centrifugal force which is generated in the pump push the liquid to move out. The impeller is the device which rotates and transfer energy to the fluid.

We fabricate the centrifugal pump that includes the end-suction and back-pullout type centrifugal pump. Our heavy duty pump is capable to handle a wide spectrum of corrosive chemicals, starting from strongly oxidizing solutions to strongly reducing ones, at different temperatures and concentration, which can be used in different process plants.

Cross Sectional Drawing:

Salient Features:

  • Heavy duty process design
  • High Efficiency
  • Back pullout design makes inspection and maintenance process easy.
  • Low maintenance
  • High productivity due to three bearing design

Our centrifugal process pumps are manufactured using graded gray cast iron carbon steel, Brass, and many other materials. We also provide other optional accessories which include M.S Fabricated base frame, superior quality of flexible coupling & coupling guard and Foundation Bolts.

Download
Our 2023-24
Centrifugal Pumps
Catalog



Download Now

Technical Specification:

Type End-Suction and Back-Pullout Type Centrifugal Pump
Capacity up to 1100 m3/hr
Head up to 150 Meter
Pressure up to 15 kg/cm2
Size 25mm to 300mm
Speed up to 3500 rpm
Temperature up to 350° C
M.O.C. CI, CS, SS304 / 316, SS 304 L/316L, Alloy 20, Hast alloy B or C,CD4MCU, etc…

Centrifugal Process Pump – SCPP Series

Centrifugal Process Pumps are used in following applications and industries:

  • Hot and Cold Water Circulation
  • Cooling Towers Installation
  • Paper Industries
  • Thermic Fluid Boiler
  • Heat Exchanger
  • Chemical Industries
  • Sugar Plants
  • Textile Industries
  • Ceramic Industries
  • Solvent Transfer
  • Food Industries
  • Laminate Industries
  • Marine/Ports
  • Automobile Industries
  • Seawater and in many more industries and applications
